Brand new for Baja Designs is our SAE certified light. This light is based off of our Squadron series. While there are many visual characteristics that stayed the same the pattern, and circuitry are optimized in order to give our SAE light a street legal punch!
We’ve put this light through rigorous tests to ensure that it would be an upgrade from most LED, HID, and Halogen factory fog lights.
This kit includes vehicle specific brackets for the listed vehicle(s) below.
Ford Bronco Sport 21+ SAE Plastic Bumper Fog Pocket Kits
- Ford Bronco 2021+
- Ford Ranger 2019-2023
NOTE: w/OE Plastic Bumper
- Limited Lifetime Warranty – Complete Purchase Protection
- ClearView® – All The Light, Right Where You Need It.
- MoistureBlock™ – Waterproof, Rain Proof, Submersible
- CopperDrive® – Only LED Driven At 100%
- 5000K Daylight – Less Driver Fatigue, Natural Color
Dimensions
Depth (in.) 2.770 Height (in.) 3.070 Length (in.) 3.070 Weight (lbs.) 0.750 Specifications
Amperage Rating (A) 2.200 Average Rated Life (hr.) 49,930 Beam Pattern Wide Cornering Bezel Material Billet Machined
Aluminum
Brightness (Lumens) 3162 Description Wide Cornering Housing Color Black Housing Material Powder Coated Cast
Aluminum
Lens Color Clear, Amber Lens Material Hardcoated Polycarbonate Light Quantity 1 Lighting Modes Beam Lighting Quantity 4 Lighting Technology LED Lighting Type Forward Projecting Mounting Hardware
Included
Yes Mounting Hardware
Material
Stainless Steel Overvoltage Protection Built-In Product Type Squadron Sport LED Pod Wattage (W) 30.360 Wiring Harness Included No Standards & Compliance
Standards/Compliance
(Durability)
Exceeds MIL-STD810G
(Mil-Spec Testing)
Standards/Compliance
(Impact Resistance)
IK10 Compliant
(Mechanical Impact Testing)
Standards/Compliance
(Water Resistance)
IP69K (Waterproof up to
9ft & Pressure Washable)
- Warranties on our products vary by product and/or by industry, as listed below. All warranty returns require a Return Authorization form as described below.
- Warranties cover defects in design and manufacturing only. Warranties do not cover, among other things: installation errors, wear and tear, acts of God, misuse, abuse, neglect, accidents, collisions, defects due to custom specifications provided by you, or any product modifications, configurations or combinations not performed by us or on our behalf. Also note the exceptions below for third-party products.
- Warranty periods start on the shipment date.
- For all warranty returns, we will pay the freight costs on the condition that you return the defective product within 90 days of delivery; otherwise, the product must be returned to us with freight prepaid by you. At our option and as the exclusive remedy, we will repair or replace the product in question, or issue credit. If an identical product is no longer available, we may replace with a similar product of comparable value
COMMERCIAL USE:
Light Bars and Auxiliary Lights Used for Commercial Use: This covers the following industries: Agriculture, Industrial, Mining, and Public Safety.
Warranty Period: 5 years or 49,930 hours of operation, whichever comes first. You must be the original owner with proof of purchase upon claim or proof of product registration.
RECREATIONAL USE:
Light Bars and Auxiliary Lights Used for Recreational Automotive/Off Road: This covers lights bars and auxiliary lights.
Warranty Period: Limited lifetime warranty or 49,930 hours of operation, whichever comes first. You must be the original owner with proof of purchase upon claim or proof of product registration.
Third-Party Products: This covers brackets, wiring harnesses, handlebar switches etc.
Pass-Through Warranty: We resell, and are not the manufacturer of, certain third-party products including those listed above. We make no express or implied warranties on third-party products and the warranty coverages above do not apply to these products. We will, however, pass through all warranties offered by the manufacturer, who has sole responsibility for processing warranty claims and returns. In all cases, unless otherwise agreed by the manufacturer, you must be the original owner with proof of purchase upon claim or proof of product registration.
-Warranties submitted without RMA form will not be processed
Bronco Plastic Bumper Specific
